BLITZ Conventional Fire Alarm Control Panel, designed for reliable property protection and advanced control.

Here is a brief breakdown of its key features and specifications:

Core Features

• Zone Capacities: Available in 16 & 24 fixed zones.
• Device Support: Supports up to 25 detectors combined with a manual call point on each individual zone.
• Outputs: Equipped with 1 "Fire" and 1 "Fault" relay outputs, alongside 2 sounder outputs.
• Build & Power: Housed in a durable metal case and includes a 12V / 4Ah Sealed Lead Acid battery with over-discharge protection.

Technical Specifications

• Power Supply: Operates on a mains supply voltage of AC 220~230V (50Hz / 60Hz) with an internal power supply of DC 27V nominal.
• Current Ratings: Features a rated current of 130 mA and a total current-limited output of 400 mA.
• Dimensions: Measures 330 x 100 x 270 mm (Width x Height x Depth).
• Environment: Designed to operate in temperatures ranging from 0 to 40°C.
