Blitz Conventional Fire Alarm Control Panel.

Key Features

• Zone Capacity: It is a 4-fixed zone panel.
• Detector Support: Supports up to 25 detectors combined with manual call points per zone.
• Outputs: Equipped with 1 "Fire" and 1 "Fault" relay output, alongside 2 sounder outputs.
• Build & Battery: Housed in a durable metal case. It includes a 12V / 1.3Ah Sealed Lead Acid battery with over-discharge protection.

Technical Specifications

• Power Supply: Operates on an AC 220~230V mains supply voltage (50Hz / 60Hz frequency) with a rated current of 130 mA.
• Internal Power: DC 27V nominal for internal power supply and auxiliary power output.
• Dimensions: Measures 270 x 80 x 200 mm.
• Operating Temperature: Suitable for environments ranging from 0 to 40°C.

Certifications

• The product is CE marked and ISO 9001 certified.
