Blitz Conventional Photoelectric Smoke Detector is a fire safety device designed to provide early warning of smoke presence, specifically targeting slow, smoldering fires.

Key Technical Specifications

• Detection Type: Photoelectric sensing technology.
• Operating Voltage: DC 9V to 28V.
• Current Consumption: Standby current is ≤ 50 μA; alarm current is ≤ 50 mA.
• Dimensions: 100mm in diameter and 52mm in depth (including the base).
• Operating Environment: Functions between -10°C to +50°C with relative humidity up to 95% (non-condensing).
• Indicators: Features a built-in red LED indicator that lights up during an alarm.
• System Compatibility: Designed for standard, conventional fire alarm control panels.

Ideal Applications

It is certified (CE and ISO 9001) for use in early-detection commercial and public environments, including:

• Offices and schools
• Hospitals and warehouses
• Corridors and stairwells
