Blitz Conventional Fire Alarm Control Panel, specifically highlighting its 8-zone configuration and key operational features.

Key Features

• Zone Capacity: Supports 8 fixed zones with up to 25 combined detectors/manual call points per zone.
• Outputs: Equipped with 2 sounder outputs, along with dedicated "Fire" and "Fault" relay outputs.
• Build & Backup: Features a durable metal case, LED indicators for all zones, and a built-in 12V / 1.3Ah Sealed Lead Acid battery with over-discharge protection.

Technical Specifications

• Power Supply: AC 220~230V (50Hz / 60Hz) input voltage with a rated current of 130 mA.
• Internal & Aux Output: DC 27V nominal.
• Current Limits: Total output current is limited to 400 mA, with a maximum source current of 30 mA.
• Dimensions: 270 x 80 x 200 mm (WxHxD).
• Operating Temperature: Designed to operate between 0 – 40°C.
